Product
Manufacturing Capacity
Tubesheet(Tube Plate), Baffle, Support plate, Ring & Flange
OUTSIDE DIAMETER: Maximum Ø5000MM for Tubesheet (Tube Plate) Maximum Ø6300MM for Ring & Flange
THICKNESS: Maximum 750MM
TUBE HOLE DIAMETER：Maximum Ø120MM
Materials:
Carbon Steel & Alloy Steel: ASTM A516 Gr.70, ASTM A105, ASTM A266 Gr.2, ASTM A182 F1, F2, F5, F9, F11, F12, F22, F6a, F6NM, F91, ASTM A350 LF1/LF2/LF6
Stainless Steel & Duplex Steel:
ASTM A240 Gr.304, 304L, 304H, 316, 316L, 316Ti, 321, 321H, 310S, 310H, 310MoLN, 317L, 347, 347H, 904L, AL-6XN(N08367), Duplex 2205(S31803 & S32205), Duplex 2507(S32750), 410, 444, 253MA, 254SMO(S31254)
ASTM A182 F304, F304L, F304H, F316, F316L, F316Ti, F321, F321H, F310, F310H, F317L, F347, F347H, F20(N08020), F44(S31254), F51(S31803), F53(S32750), F60(S32205), F62(N08367), F904L
Nickel & Nickel Alloy: Nickel 200, Nickel 201, Monel 400, Incoloy 800/800H/800HT/825/901/926, A-286, Inconel 600/601/625/718/X-750, Hastelloy B/B-2/C-4/C-22/C-276, Invar 36
Titanium & Titanium Alloy: ASTM B265 Gr.1, Gr.2, Gr.7, Gr.12
ASTM B381 F1, F2, F7, F12
Copper & Copper-Nickel: C46400, C61400, C70600(10% Ni, 90% Cu), C71500(30% Ni, 70% Cu)
Clad Materials: Explosive Cladding(SS/CS, Ni/CS, Cu/CS, Ti/CS, Ti/SS, Cu/SS, Ni/SS, Ti/Cu, Ti/Ni) & Overlay Welding
Our Machining Facilities
Our Drilling Facilities
